「快速門編碼器」鄂爾多斯堆積門絕對值編碼接線方法

Absolute Value Coding Connection Method for "Fast Gate Encoder" Stacking Gate

快速卷簾門的限位有兩種方式,一種機械限位定位方式，一種編碼器定位。


There are two ways to limit the fast curtain door, one is mechanical limit positioning, and the other is encoder positioning.


以前許多廠家為了節省成本，通常都會應用機械定位方式，這種機械限位造價成本低，但是帶來的問題是調試快速卷簾門限位麻煩，通常需要10~20分鐘才能定位準確。


In order to save costs, many manufacturers used to use mechanical positioning method. This kind of mechanical limit cost is low, but the problem is that it is difficult to debug the fast rolling shutter threshold. It usually takes 10 to 20 minutes to locate accurately.

而編碼器限位則相對要簡略許多，而且具備定完精準，不移位的優勢，由于在斷電的情況下，它是不記憶行程的。


The encoder limit is relatively much simpler, and has the advantage of precision and non-displacement, because in the case of power failure, it does not remember the journey.


機械定位方法與常見的鋼制卷閘門相差無幾，由于不常用，這里不做過多的介紹了。


The mechanical positioning method is almost the same as the common steel coil gate. Notes for debugging the interlocking stacking gate of Zhangjiakou Express Gate are not introduced too much here because it is not commonly used.


「快速門編碼器」鄂爾多斯堆積門絕對值編碼接線方法


Absolute Value Coding Connection Method for "Fast Gate Encoder" Stacking Gate

就分辨率為1024的編碼器而言，這里就以龍盛門業的產品為例，它能夠?qū)?米高的快速卷簾門分解成9000個點，因而它的準確度能夠達到0.3毫米。能夠由一個按鍵來恣意操控高度。


For the encoder with 1024 resolution, take Longshengmen's products as an example. It can decompose the 3-meter-high fast shutter door into 9,000 points, so its accuracy can reach 0.3 mm. It can control height arbitrarily by one button.

如只過人的快速門高度為2米就能夠了，但若是有巨大物體通過，如叉車，那么咱們就需要在從頭設置如下高度。


If the height of the fast door is only 2 meters, but if a huge object passes through, such as a forklift, then we need to set the following height from scratch.


編碼器接線方式


Encoder wiring mode


1、電機安裝在右側：紅色線接+24，綠色線接-24，黃色線接XO，白色線接X1，黑色線接X2


1. The motor is installed on the right side: red connection + 24, green connection - 24, yellow connection XO, white connection X1, black connection X2.


2、電機安裝在左側：紅色線接+24，綠色線接-24，白色線接XO，黃色線接X1，黑色線接X2


2. The motor is installed on the left side: red wire connection + 24, interlocking stacking door of Zhangjiakou Express Gate debugging precautions, green wire connection - 24, white wire connection XO, yellow wire connection X1, black wire connection X2


3、備注：紅色線、綠色線、黑色線接線方式始終不變。黃色線和白色線更急電機左右裝機需兌換。


3. Remarks: The wiring mode of red, green and black lines remains unchanged. Yellow and white lines need to be converted when the motor is installed right or left.
