「包頭保溫快速門」車間防寒快速門定做


Customized Cold-proof Fast Door for Baotou Thermal Insulation Fast Door Workshop


保溫快速卷簾門是普通快速卷簾門的升級版，普通快速卷簾門雖然已經有了很好的密封、隔離、保溫效果，但是針對某些特定的使用場所，它的性能還是沒法滿足使用需求，所以就有了它的升級版，保溫快速卷簾門。


Insulation fast rolling shutter door is an upgrade version of ordinary fast rolling shutter door. Although ordinary fast rolling shutter door has a good sealing, isolation, insulation effect, but for some specific places of use, its performance can not meet the needs of use, so there is its upgrade version, Insulation fast rolling shutter door.


保溫快速卷簾門的門簾，在普通快速卷簾門的門簾基礎上，進行了升級，可以滿足對保溫效果要求較高的場所進行使用。


The curtain of thermal insulation fast rolling shutter door is upgraded on the basis of ordinary fast rolling shutter door curtain, which can be used in places with high thermal insulation effect requirements.

在寒冷的冬季，廠房車間室內外溫差較大，如果氣密性不高，導致室內外空氣形成壓力差，室外冷空氣通過縫隙進入室內，造成室溫劇烈波動，影響室內環境并消耗大量熱能，這種現象我們稱之為“冷風滲透”


In cold winter, the temperature difference between indoor and outdoor of workshop is large. If the air tightness is not high, the pressure difference between indoor and outdoor air will be formed. The outdoor cold air will enter the room through cracks, resulting in drastic fluctuation of room temperature, affecting the indoor environment and consuming a lot of heat energy. This phenomenon is called "cold air infiltration".


;而在夏季炎熱的天氣，室外的高溫天氣及室內采用空調制冷，空氣流動產生的熱風通過縫隙進入室內，導致制冷能耗增加。


In hot summer weather, outdoor high temperature weather and indoor air conditioning refrigeration, the hot air generated by air flow enters the room through the gap, resulting in an increase in refrigeration energy consumption.



無論是寒冷的天氣還是炎熱天氣下，如果在氣密性和保溫隔熱性不好的情況下，室內外的溫差都將導致企業成本的增加和能源的浪費


Whether in cold or hot weather, if the air tightness and thermal insulation are not good, the temperature difference between indoor and outdoor will lead to the increase of enterprise costs and waste of energy.


因此，保溫快速卷簾門的氣密性能和保溫隔熱性能，是其企業節省能源的一個重要措施。


Therefore, the air tightness and heat insulation performance of the fast curtain door is an important measure to save energy for its enterprises.


保溫快速卷簾門采用新型高頻焊接技術，全自動拼接一次成型，且門簾底部裝有氣囊布兜，能同各種不平坦地面密封結合，軌道內置毛刷，以達到高度密封保溫效果。


The new high frequency welding technology is adopted for the thermal insulation fast rolling curtain door, which is fully automatic splicing and forming at one time. The bottom of the curtain is equipped with air bag cloth pocket, which can be sealed with various uneven ground, and the guide rail has built-in brush to achieve high sealing and thermal insulation effect.


「包頭保溫快速門」車間防寒快速門定做


Customized Cold-proof Fast Door for Baotou Thermal Insulation Fast Door Workshop


技術參數：


Technical parameters:


開啟速度：0.6-1.5m/s；關閉速度0.6-1.0m/s。


Opening speed: 0.6-1.5m/s; Closing speed: 0.6-1.0m/s.


門簾特性：使用2.0mm工業機器人快速卷簾門專用門簾，具有很好的耐磨和防尖銳物體劃破特性，透明視窗具有防氬弧焊功能。


Door curtain characteristics: 2.0mm industrial robot is used to roll the special door curtain for fast shutter door. It has good wear resistance and anti-sharp object scratch characteristics. Transparent window has anti-argon arc welding function.


密封隔絕：底部裝有彈性的PVC基布氣密封，它可與各種不平坦地面精密結合，門柱密封采用特有的雙層毛刷增加了更好的密封性。


Sealing isolation: The bottom is equipped with elastic PVC base cloth gas seal, which can be precisely combined with a variety of uneven ground. The unique double-layer brush for door post seal increases the sealing performance.


獨特的密封系統，高效的密封方式，有效地隔絕氣味、噪音和粉塵的傳播。


Unique sealing system, efficient sealing method, effectively isolate the spread of odor, noise and dust.


門體框架：門框及門箱材質為2.0mm厚優質冷軋板鋼構，優質烤、噴漆工藝處理；1.8mm厚不銹鋼或3.5mm高強度6063抗氧化工業鋁合金立柱。


Door Frame: Door Frame and Door Box are made of 2.0mm thick and high quality cold-rolled steel plate, treated by high quality baking and spraying technology, 1.8mm thick stainless steel or 3.5mm high strength 6063 anti-oxidation industrial aluminium alloy column.


動力系統：德國菲瑞普工業快速卷簾門專用電機。


Power System: Special Motor for Fast Rolling Shutter Door of German Philip Industry.


控制系統：SUPER II工業快速卷簾門專用控制系統，電控箱IP54標準防水防塵。性能更穩定的多圈絕對值編碼器，控制系統可與設備進行聯動作業。


Control system: SUPER II industrial fast shutter door special control system, electronic control box IP54 standard waterproof and dust-proof. Multi-loop encoder with more stable performance, and the control system can operate in conjunction with the equipment.
